Artifacts

Research, renderings, drafting, and production material.

The Merry Wives of Windsor Cove Read the article
Scenic Research Mood Board Early Storefront Rendering Overhead Rendering Study Final scenic rendering for The Merry Wives of Windsor Cove, showing the audience-wrapped surf-town architecture and central playing space at New Swan Theatre Company. Ground Plan Storefront Elevation Awning Details Banana Stand Paint Elevation Banana Stand Counter in the Shop Painting the Banana Stand Surf Shack Paint Elevation Welcome to Windsor Cove Sign Quickly’s Banana Stand Sign Quickly’s Banana Stand in Tech A Kraken for Quickly’sVideo
All artifacts
01 / 16 Production page
01 · ResearchOpen image

Scenic Research Mood Board

Surf shacks, Balboa banana stands, surfboard signage, and striped awnings from the original scenic research.

Production page
02 · RenderingOpen image

Early Storefront Rendering

An early study of the banana stand, center arch, and surfboards beneath the upper gallery.

Production page
03 · RenderingOpen image

Overhead Rendering Study

The early overhead view shows the storefronts at one end of the playing space and the seating wrapped around it.

Production page
04 · RenderingOriginal image

Final scenic rendering.

Final scenic rendering for The Merry Wives of Windsor Cove, showing the audience-wrapped surf-town architecture and central playing space at New Swan Theatre Company.

Production page
05 · DraftingOpen image

Ground Plan

The ground plan locates the storefronts in relation to the open floor and surrounding audience.

Production page
06 · DraftingOpen image

Storefront Elevation

The main elevation coordinates the center arch and storefronts with the upper gallery.

Production page
07 · DraftingOpen image

Awning Details

Construction views show how the two storefront awnings are shaped and assembled.

Production page
08 · Paint elevationsOpen image

Banana Stand Paint Elevation

Blue and cream finish samples accompany the counter and striped awning elevations.

Production page
09 · Shop photosOpen image

Banana Stand Counter in the Shop

The counter in the shop before the blue finish.

Production page
10 · Shop photosOpen image

Painting the Banana Stand

The deep blue finish going over the horizontal panel stock.

Production page
11 · Paint elevationsOpen image

Surf Shack Paint Elevation

Wood tones and weathering details for the Surf Shack storefront and awning.

Production page
12 · GraphicsOpen image

Welcome to Windsor Cove Sign

The town name sits on a surfboard-shaped sign above the central arch.

Production page
13 · GraphicsOpen image

Quickly’s Banana Stand Sign

A peeled banana carries the name of Quickly’s storefront.

Production page
14 · Tech photosOpen image

Quickly’s Banana Stand in Tech

The banana sign and striped awning in place at New Swan.

Production page
15 · Process filmOpen video

A Kraken for Quickly’s

3D printed and hand-painted for Quickly’s Banana Stand during tech.

Production page
